Name: ROTOCON 4-SPINDLE TURRET REWINDER WITH HOTMELT GLUE OR GLUELESS
Availability: InStock

ROTOCON 4-SPINDLE TURRET REWINDER WITH HOTMELT GLUE OR GLUELESS OPERATION

‍

Advanced turret rewinding with hotmelt or glueless operation for efficient, high-quality output.

ROTOCON TR HM 4 Spindle Turret NON STOP Rewind Solution WITH Hotmelt GLUE 350 450

The ROTOCON Automatic 4-Spindle Turret Rewinder with hotmelt glue or glueless operation keeps finishing lines moving with continuous rewinding and automatic roll changeover, allowing operators to unload finished rolls and prepare new cores without stopping production and reducing costly setup and changeover times. It delivers superior winding performance with multi-servo precision tension control across a wide range of substrates, making it especially suited for labels produced on heat-sensitive substrates or using heat-sensitive inks, finishes, or decorations.

‍

No items found.

Features

Continuous Turret Rewinding

Enables non-stop production with uninterrupted roll winding for maximum efficiency.

Automatic Roll Changeover

Seamlessly switches rolls without stopping the line, reducing downtime and manual intervention.

Dual Hotmelt or Glueless Operation

Provides flexible web-to-core fixing options to suit different materials and production needs.

Innovative Glueless Start Technology

Eliminates adhesive use while ensuring clean, secure roll starts and reduced consumable costs.

Electronic Web Tension Control

Maintains precise and consistent tension for superior winding quality across all substrates.

Automatic Core Alignment and Loading

Ensures accurate core positioning and fast preparation for improved productivity and reduced waste.

High-Speed Performance up to 150 m/min

Supports fast, efficient production while maintaining precision and roll quality.

Advanced Web Handling System

Includes electronic web guiding and edge trim extraction for smooth operation and clean finishing.

‍

Details

Discover detailed information, technical specifications, and key performance facts for each individual machine right here.

Specifications

Maximum Working Web Width

Hotmelt: 350 mm (13.78"), 450 mm (17.72"), 530 mm (20.87") · Glueless: 530 mm (20.87")

Maximum Mechanical Speed

Up to 150 m/min (492 fpm)* — both versions

Maximum Rewind Diameter

Hotmelt: 350 mm (13.78") · Glueless: 260 mm (10.24")

Minimum Lane Width

Hotmelt: 60 mm (2.36") · Glueless: 40 mm (1.57")

System Type

Hotmelt: automatic hotmelt glue system · Glueless: glueless system

Finished Roll Unloading

Included — both versions

Core Alignment & Loading

Automatic — both versions

Rewind Spindle Configuration

4 spindles: 25.4 mm (1"), 38.1 mm (1.5"), 76.2 mm (3")

Web Tension Control System

Electronic web tension control for consistent and precise rewinding

Drive System

Lenze servo drive for accurate speed control and reliable performance

Core Handling System

Automatic core loader and automatic bowl feeder with exit feeder for cores 25.4–38.1 mm (1"–1.50")

Slitting Capability

Manual slitting unit with 10 knives for flexible job setup

Power Requirements

Hotmelt: 380 V, 3P/N/PE, 16 kW, 25 A, 50/60 Hz · Glueless: 380 V, 3P/N/PE, 10 kW, 16 A, 50/60 Hz

Compressed Air

6–8 bar (approx. 87–116 psi) — both versions

Network Connection

Required — both versions

Standard Configuration (both versions)

Clear-on-clear sensor · Interface for other presses (start, stop, jog, slow down, safety interface) · Finished roll collection · Mandrel constant end support · Quick-change mandrel function · Electronic web guide · Web edge trim extraction

Note

*Maximum speed depends on options, material, and application
